10D Amplifier

The d&b 10D amplifier is a 2RU, four-channel unit designed for fixed installations that demand high-quality performance at lower SPL levels. With advanced input m anagement, individual input gain control, GPIO, and fault monitoring, it ensures reliable operation, even in emergency situations.

Built on the same DSP platform as d&b’s latest amplifiers, the 10D supports smaller d&b loudspeakers and features a linear mode. It offers two 16-band EQs per channel, extensive delay options up to 10 seconds, and flexible filtering including parametric and notch filters.

The 10D connects via Ethernet (OCA protocol) or CAN-Bus and can be controlled through a browser-based web interface or d&b’s R1 Remote software. Additional features include LoadMatch for cable compensation, a Class D design with active PFC, and stable operation across a wide voltage range.

For high-SPL applications or use with larger systems like the SL-Series or V-Series, the 30D amplifier is recommended.

Installation-specific four channel 10D amplifier

• Delivers up to 4 x 700 W into 4 Ω output power.
• Compatible with all current d&b loudspeakers except A-Series, J-Series, SL-Series, V-Series, M2, and B22-SUB.
• Features 5 configurable GPIOs plus a general fault contact for external control and system monitoring.
